M12 - 8 Pin Male Plug - A Coded Cable Mount Connector
Product ID: 76178075053579
Product SKU:TB-M12005
Product is in stock hurry now!
₹899.00₹ 1,199.00
(25% OFF) Parameter | Value |
|---|---|
Connector Type | M12 8 Pin Cable Mount Connector |
Contacts Poles | 8 Pin |
Connector Gender | Male |
Coding | A-Coded |
Mounting Type | Cable Mount |
Coupling Thread | M12 × 1.0 |
Rated Voltage | 30 V |
Current Rating | 2 A |
Contact Resistance | ≤ 5 mΩ |
Insulation Resistance | ≥ 100 MΩ |
Dielectric Withstanding Voltage | 1000 VAC |
Degree of Protection | IP67 (Mated Condition) |
Contact Material | Copper Alloy (CuZn) |
Contact Plating | Gold Plated |
Contact Carrier | PA66 (Nylon 66) |
Housing Material | Brass, Nickel Plated |
Seal Material | NBR / Neoprene |
Termination Type | Screw Type |
Cable Outlet Diameter | 4 mm – 8 mm |
Operating Temperature | -25°C to +85°C |
Grip Colour | Black |
